EN
| Adjustment range |
0°C ÷ 200°C |
|---|---|
| Maximum ambient temperature |
T210 |
| Rated voltage current |
10 A / 250 V - 400 V ---- 16 A / 250 V - 400 V |
| Built in accordance with the standard |
EN 60730-2-9 |
| Minimum current |
200 mA std - 10 mA contatti dorati |
| ENEC (EN 60730) approved - cycle number |
100.000 (10A/250V) - 30.000 (16A/250V) |
| Other application areas | |
|---|---|
| Heating systems | |
| Large home appliances | |
| Small home appliances |
The tolerance ranges on the operating temperature and the differential can vary depending on the application and the required nominal temperature. The thermostat controls the temperature per contact. On request, with extra charge, execution with gold-plated contacts and silver or prestonized fastons for contact resistance typical of 5mOhm; Execution with N.A. contacts only with aluminum cap and Temp. Max. intervention 150 ° C. Possibility of temperature color code.
